with warm air recirculation
with container discharge
output 25,000 m3/h
filter area 273 m2
filter width 2,700 mm
filter height 6,720 mm
filter length 7,300 mm
weight 5,500 kg

- Powerful extraction center for entire machine
  parks
- Energy-saving miracle thanks to performance-
  adapted fan control
- Dust-tested: H3 test mark, dust class “M”
- Can be combined with various chip discharge
  systems

Volume flow: 1.593 m³/h
Motor power: 2,2 kW
Negative pressure: 2.200 pa
Filter surface area: 9,5 m²

Volume flow: 1.593 m³/h
Motor power: 2,2 kW
Negative pressure: 2.200 pa
Filter surface area: 9,5 m²

- Nominal volume flow 6297 m³/h
- 49,6 m² filter surface
- Residual dust content <0.1 mg/m³

- Nominal volume flow 5089 m³/h
- 31,8 m² filter surface
- Residual dust content <0.1 mg/m³

- Nominal volume flow 3534 m³/h
- 25,4 m² filter surface
- Residual dust content <0.1 mg/m³

- Nominal volume flow 2262 m³/h
- max. volume flow 3200 m³/h
- 14,1 m² filter surface
- Residual dust content <0.1mg/m³

- Nominal volume flow 1448 m³/h
- Associated negative pressure 3000 Pa
- 10.6 m² filter surface
- Residual dust content <0.1mg/m³

Antriebsmotor: 7,5 kW
Saugstutzen Ø 300mm
Volumenstrom: 5950 m³/h
Abmessungen (LxBxH) 3550 x 1580 x 2570mm

Variante mit motorischer Filterreinigung.
Kein Druckluftanschluss notwendig.

привод: 4 kВт, 400 Вольт, 50 Гц, 3 фазы
площадь фильтра: 14,5 м²
очитска фильтра: пневматически
потребление воздуха: прибл. 3,5 л. при 8 бар
звуковая нагрузк: 75 dB (A)

Drive motor: 3 kW
Nominal volume flow: 1832 m³/h
Connection diameter: 180 mm
Filter surface: 13,5 m²
Filter cleaning: motorical (no compressed air connection needed)

Drive motor: 3 kW
Nominal volume flow: 1832 m³/h
Connection diameter: 180 mm
Filter surface: 13,5 m²
