- Complete edge processing up to 3 mm thickness
- with KFA-30 units
- with workpiece return

Jointing unit
VTG gluing unit
Pre-milling unit
Multiple profile trimming unit
Contour trimming unit KFA x 20
Multiple profile scraper unit
Scraper
Buffing unit
Standard trimming unit for grooving/rebating and profiling

New control system in 2020
Premilling unit
Gluing unit PU + HOT-AIR with 12-coil magazine
Endtrimming unit from top
Roughmilling unit top and bottom
MFA - contour milling unit with 2 motors
Profile scraping unit
Edge finish brushing unit LCM
Grooving aggregate pneumatic in/out
Inclusive LIGMATECH returning device with Wandres belt-cleanig unit from bottom

Универсальное применение для дверей, столешниц, деталей мебели, изогнутых фасадов караванов и т. д.

One-sided edge banding machine for processing straight workpiece edges and for gluing and reworking various edge materials in longitudinal and transverse throughput.
- with Lasertec and PU gluing
- with vacuum portal returning system Barbaric

workshop-checked with:
- new transport chain
- new top pressure
- rebuilt edge magazine including gluing unit

Left hand machine

- новый станок в наличии на складе
- максимальная гибкость в выборе кромочного материала и формы заготовки
- поворотный стол 0 ° - 45 °

- Jointing cutter
- Radiant heater
- EVA gluing unit
- Roll magazine for edge material
- Cutting unit
- Flush milling top/bottom
- MFA with 2 motors for radius r2, servo-controlled
- Profile scraper unit
- Surface scraper unit
- Buffing unit
- Feed speed 20 m/min

- joint milling
- Gluing section with glue premelter
- Pressure zone
- Snipping unit
- Flush trimming
- Contour trimming unit FK 13 with automatic tool changer 8-fold
- Groove trimming unit
- Profile scraper
- Surface scraper
- Buffing unit
- Homatic NC 21 control unit

- Jointing milling unit with 2 motors, each 4.5 kW
- Infrared heater, approx. 300 mm long, 2 x 1.5 kW
- Gluing unit
- Vertical roll holder for 32 rolls
- End trimming unit on top pressure beam with 2 motors, each 200 W
- Milling unit with 2 motors, each 1000 W
- Multi-functional processing unit 2 motors 660 W
- Spray nozzles top and bottom
- Multi-profile scraper unit
- Flat scraper unit
- Copy buffing unit 4 motors 250 W
- Smoothing unit

- Touchscreen control
- Joint milling
- Gluing unit with two Teflon-coated glue pans
- Release agent dispenser
- Snipping unit
- Pre-milling unit
- Rounding unit
- Profile scraper blades
- Surface scraper blades
- Buffing unit

- Release agent specification top/bottom
- Joining unit and blow nozzle
- Cutting unit
- Copy trimming unit SKF-L
- Profile scraper unit
- Spray cleaning agent
- Self-scanning scraper unit
- Buffing unit

- Joint trimming unit
- Gluing unit
- Snipping unit
- Pre-milling unit
- Shaping trimming unit
- Profile scraper blades
- Surface scraper blades
- Buffing unit
- Grooving unit

- With workpiece return
- Maximum edge thickness: 20 mm
- Panel thickness: 8-60 mm
- Maximum feed rate: 20 m/min
- With grooving unit

- Joining unit 2 x 2.2 KW 200Hz
- Gluing unit A12
- Snipping unit chamfer/straight 2 x 0.35 KW
- Trimming unit 2 x 0.55 KW counter rotation
- Grooving unit 1 x 1.85 KW Swiveling
- Shaping trimming unit 2 x 0.35 KW WD 60
- Profile scraper blades with quick-change heads
- Free space glue joint scraper
- Buffing unit

- Automatic feeding table
- KFA milling unit
- Workpiece returning system

- Подающий стол
- наклейка ПУР или ЛАЗЕР
- KFA агрегат

- с подающим столом для геометрии
- с аггреатом KFA
- c пазовальным узлом

- оборудование применяется для
предварительного разогрева клея в клеевом
бачке
- для быстрой смены клеевых бачков или для
выполнения ремонтных или очистных работ
клеевых бачков

- станок для постформинга для кухонных столешниц
- с програмным управлением Beckhoff control
- новый станок с производства WEHRMANN SPECIAL MACHINE

- adaptable to all common machine manufacturers
- PTFE coating reduces maintenance and cleaning costs

with:
- Tiltable trimming unit ( with 1 high frequency motor HP 0.75 (kw0,55)
- 1 cutter Head with 2 knives 1 straight 15 degrees, the other 2 mms radius
